Power Module

MARIGOLD-5

The Marigold-5 is a compact DC-DC power module for the FIRST Robotics Competition. It delivers a high-current 5.1V USB-C output for co-processors plus an auxiliary port for peripherals, staying stable all the way down to 6V.

$24.99USD Buy Now
Technical Specifications
Input Voltage
6V – 18V
Output Voltage
5.1V
Output Current
5–6A continuous, 7A validated
Mounting
4-40 & 6-32
Why Marigold-5?
Brownout-Resilient Power
Many 12V adapters are not designed for deep battery sag. Marigold-5 is rated down to 6V to keep your co-processor powered through demanding matches.
5–6A Continuous Output
Power a vision co-processor and additional peripherals simultaneously. High continuous current with headroom available for spikes.
Quick Swap
Push-button wiring connector and locking USB-C. Replace a unit between matches, no soldering required.
What's in the Box
  • 1× Marigold-5Fully Assembled
  • 1× Larkspur StickerVinyl
  • 1× Quick Mount JigPaper
  • 1× Wiring GuidePamphlet
Read the Docs
